Engine Details

Model:

Xichai/Weichai ZH4102 turbo engine

Engine type:

In-line arrangement, water-cooled, four-cycle diesel Engine

Rated Power:

57/57-60KW

Rated Speed:

2200 r/min (rpm)

Fuel Consumption ratio in standard working condition:

243g/kw.h

Transmission System

Torque Converter Model

YJ280

Gear Box Model

YJB152 YJB152A

Type:

Fixed-spindle Power shift

Shift gear control oil pressure:

1.2-1.5MPa

Rated input speed:

2500 (rpm)

Speed

Gear Shift

2 Forward Shift, 2 Reverse Shift

Max Speed

24km/h

Bucket

Bucket Capacity:

800kg

Bucket width:

1620mm

Bucket type:

Heavy-duty bolt on teeth

Max. Breakout Force:

36KN

Rated Load:

800kg

Operating Weight:

4800kg

Overall Dimensions

(1) Overall Length (Bucket on ground position):

6200mm

Overall Height

(a) Ground to Cab

2700mm

(b) Ground to exhaust pipe:

It is below from the top of cabin

(c) Dumping Height:

4300mm

Overall Width:

2000mm

Operating Specifications

Steering System:

Articulated Frame with hydraulic power steering

Min Turning Radius:

4800mm

Driving System:

Hydraulic converter

Brake System

Tyre Size

20.5-70-16 or 1670-20

Service Brake:

Four Wheel Hydraulic spread-shoed brake

Parking Brake:

Hand operated

7.0 Wheelbase:

1400mm

8.0 Track:

2005mm
